- Size: 2
- Place of Origin: Dongguan, China
- Brand Name: HongTu
- Model Number: HTPV-07
- Weight: 600.000 kg
Wet laakage Current Testing Machine for PV Module
Wet leakage Current Testing Machine for PV Module Standard
It's according to IEC61215 standard
Wet leakage Current Testing Machine for PV Module Purpose
It's to evaluate the insulation of the module under wet operating conditions and verify that moisture from rain, fog, dew or melted snow does not enter the active parts of the module circuitry , where it might cause corrosion , a ground fault or safety harzard
Wet leakage Current Testing Machine for PV Module Specifications
1、Test tank
Size:2100*1000*250mm(W*D*H),thick:15mm
Material:Insulation resistance PP material,nice strength,high insulation,corrosion resistance
2、constant temperature system, by HOTOTECH research and development , can heating and cooling Temperature:22±3℃
3、liquid resistivity : Less than 3500Ω·cm
4、Liquid surface tension:Less than 3N · m
Spray system:spray adopt UL lab special spray 3 pieces, every spray with water pressure gauge and water flow control value, it’s can doing multi direction spray water pressure and water flow can be adjusted for the junction box
5、Programmable insulation withstand voltage tester:
5.1 output current the max 0-5000V ( adjustable),
5.2 Leakage current the max limit value:5mA
5.3 Output speed rate:500V/s
5.4.Insulation resistance test range:1MΩ~9999MΩ
5.5 Leakage current test range:0.001~5.000mA(DC)
