PV Module Mechanical Load Testing Machine

PV Module Mechanical Load Testing Machine purpose

It's according to IECC61215, IEC61646,IEC61730 etc

PV Module Mechanical Load Testing Machine purpose

This test is to determine the ability of the module to withstand wind ,snow , static or ice loads

PV Module Mechanical Load Testing Machine specificatiosn

1、Machine table exterior size：approx L 320 × D 180 × H 195 cm

2、Test positive Load the max 5400 Pa，reverse load the max 24 00 Pa

3、Aluminum extrusion structure，The platform and support are not deformed under stress state（Aluminum surface using electrophoretic coating process，Guaranteed not to change color）

4、The max test size 120 × 240cm

5、Calibrator：350 kg

6、cylinder quantity：4 groups ,8 pieces

　　　　Cylinder outer diameter :80mm

　　　　Cylinder single group the max pressure > 6 bar

　　　　Cylinder single group the max out force > 300 kg

　　　　Cylinder Telescopic stroke：150 mm

7、sucker quantity: 8 groups , 32 pieces

　 Sucker diameter：120 mm

　　　　Each cylinder is equipped with a vacuum pressure display

　　　　The space of Between two sucker :120mm~ 400mm
