PV Module Hail Impact Testing Machine
PV Module Hail Impact Testing Machine standard
It's according to IEC61215, IEC61646,IEC61730 etc standard
PV Module Hail Impact Testing Machine purpose
It's to verify that the module is capable of withstanding the impact of hailstones
PV Module Hail Imapct Testing Machine specifications
1、The effective impact area：1200 * 2100mm
2、Standard Hail diameter：25mm±5%
3、Standard hail mass：7.53g±5%
4、Hail set speed：23.0m/s±5%
5、Speed measurement accurate：±2%
6、Hail mass measurement accurate：±2%
7、Pneumatic transmission system
8、Main function：
8.1、Chinese and English operate interface, set impact position , impact speed , hail parameter, time etc parameter
8.2、Two dimensional stepping drive system
8.3、programmable control automatic multi point impact test
8.4、Ice ball Launching speed through out pressure of compress air to adjust
8.5、light point Aiming function，convenience confirm impact point position
