Hail Impact Testing Machine for PV module   Main technical parameters

1.According to IEC61215,IEC61646

2.Effective impact area :2200×1300 (customizable )

3.Diameter of ice ball : 25mm±5%

4.The mass of ice ball :7.53g±5%

5.The specified speed of ball :23.0m/s±5%

6.speed accuracy :±2%

7.Test accuracy of ball mass :±2%

8.Accuracy about pneumatic launching system :0.2%

9.Nonrepeatability about diplacement ≤1mm

Hail Impact Testing Machine for PV module   Main function

1.Chinese interface

Interface to set the impact position, impact speed, hail parameters, time and other parameters, can Real-time display, store and print to the data

2.Transmission system with two step motors ,set up  displacement in the interface

3.Automatic multi-point impact test by programmable control

4.Adjust the launch speed of hail by the pressure of compressed air

5.laser collimation   fixed point,determine the point of impact

6.Adopt fiber-optic speed test system ,show the launch speed accurately

Hail Impact Testing Machine for PV module   Basic structure

System shall comprise: stander ,Transmission system with two step motors ,fiber-optic speed test system ,launcher , speed regulator system ,computer ,Freezer,electronic balance ,hail bracket , hail mould

The main configuration

System Controller :Mitsubishi

Laser sight :Switzerland imported

Launcher :U.S. Imports

Fiber-optic speed test system :Switzerland imports

Transmission system with two step motors :Mitsubishi

Electronic balance :U.S. Toledo

Freezer :Haier

Pressure regulating valve, solenoid valve :Japan SMC

Other important components from foreign brands and domestic brands

Company Information

  Dongguan Hong Tu Instrument Co.,Ltd , specializes in developing and producing sales of testing instrument for helmet ,photovoltaic , leather ,footwear ,luggage ,sport equipments, metal and rubber , we have firm connections and full cooperation from China's National Third-part Quality Inspection and Notarization Center on producing and developing high-precision testing machines

  We treasure the value of good quality , reasonable price and efficient service with customer satisfaction. we expert ourselves in providing our customers the best suitable testing designs and high quality testing machines to make you the utmost profit

  Please feel free to contact us for any enquires from our wide range of products

Our Services

1.High quality and best after-sell service

2.100%  quality inspection before delivery

3.Managment Innovate

4.Strong R & D team

5.Can handle customers's feedback  problems and doubt timely

6.Our testing machine have one year Warranty time
